GF型粗顆粒浮選機 Mechanical  agitating flotation machine

該浮選機為粗顆粒浮選機，適用于選別有色、黑色、貴金屬和非金屬礦物的中、小型企業，所處理的物料粒度范圍為0.74mm點45%-98%，礦漿濃度＜45%。其特點是：自吸空氣量可達1.2m³/㎡·min；自吸礦漿能從機外自吸給礦和泡沫江中礦，浮選機作業間可平面配置；槽內礦漿循環好，液面平穩，槽內礦漿無旋轉現象，無翻花；分選效率高，提高粗粒和細粒礦物的回收率；功耗低，比同規格的同類浮選機節省功耗15%-20%，同時又能吸入足量的空氣和礦漿；易損件壽命長，特別是葉輪、定子的壽命比同類浮選機延長一倍以上。

This type of flotation machine is coarse-grained flotation machine  which applies to medium and small-sized enterprises sorting nonferrous metal,  ferrous metal, precious metal and non-metallic ores. The particle size range of  the materials it treats is 0.74mm,  the 45%-98% and the slurry concentration is ＜45%. Its characteristics are: The self-absorption air amount can  reach 1.2m3/㎡·min; the self-suction slurry can automatically  suck slurry to the ore and middling ore from outside the machine. The operating  workshop of flotation machine can be allocated horizontally. The circulation of  slurry in tank is good; the liquid surface is flat; the slurry in the tank does  not rotate or roll; the separation efficiency is high and the recovery ratio of  coarse-grained minerals and fine-grained minerals is raised; the power  consumption is low (compared with similar flotation machines of the same  specifications, this type of flotation machine can save 15% to 20% of power);  besides, it can suction a sufficient amount of air and slurry; the service life  of easily damaged parts is long (the service life of vanes and rotors is  especially long. It is more than double the service life of the same type of  flotation machine.
