新一代最為暢銷的實驗室儀器。New: 強力馬達，轉速范圍廣New: 雙重溫度控制模式用于快速加熱介質。

The most popular new-generation laboratory instrument. New: powerful motors with wide speed range; new: dual temperature control mode is for rapid heating of medium

- 內置溫度控制系統
- Built-in temperature control system

- 隨機附送 PT 1000 溫度傳感器 (PT 1000.60)
-Temperature sensor model PT 1000 (PT 1000.60) attached

- 通過數顯屏可對加熱溫度和攪拌轉速進行精確控制
- Accurate control on heating temperature and stirring speed can be performed through digital display

- 數字顯示安全溫度設置
- Digital display of safe temperature settings

- 高溫警示>> ，提示用戶盤面高溫，小心燙傷
- High temperature warning prompts user for high temperature and burn

- 錯誤代碼數字顯示
- Digital display of error code

- 加熱盤安全回路可調 (5-360°C )
- Heating plate safety loop adjustable (5-360℃)

- 安全控制型加熱磁力攪拌器，適于無人操作
- Heating magnetic stirrer that can be reliably controlled for unattended operation

- DIN 12878 標準接口，可連接外部溫度及精確控溫，如： ETS-D5
- DIN 12878 standard interface for connection to external temperature and accurate control temperature, for example ETS-D5

- 先進的熱控技術，安全水平高
- Advanced thermal control technology with high level of safety

- 儀器密閉性好，保護等級高(IP 42),使用壽命長
- Outstanding tightness, high protection level (IP42), long service life

- 磁性強
- Strong magnetic

- 隨機附送 H 100 保護膜
- Protection film H100 attached

選配件: H 135.3 加熱托盤, H 135.313 1/4 加熱塊，金色，容積 4 ml, H 135.314 1/4 加熱塊，藍色，容積 8 ml, H 135.315 1/4 加熱塊，紅色，容積 16 ml, H 135.310 1/4 加熱塊，黑色，容積 20 ml, H 135.311 1/4 加熱塊，綠色，容積 30 ml, H 135.312 1/4 加熱塊，橙色，容積 40 ml, H 135.4 加熱套，用于 100 ml 圓底燒瓶, H 135.５ 加熱套，用于 500 ml 圓底燒瓶, H 135.６ 加熱套，用于 1000 ml圓底燒瓶, H 135.410 加熱套內襯，用于 10 ml 圓底燒瓶 (金色), H 135.411 加熱套內襯，用于 25ml 圓底燒瓶 (藍色), H 135.412 加熱套內襯，用于 50 ml 圓底燒瓶 (紅色), H 135.510 加熱套內襯，用于 10 ml 圓底燒瓶 (金色), H 135.511 加熱套內襯，用于 25 ml 圓底燒瓶 (藍色), H 135.512 加熱套內襯，用于 300 ml 圓底燒瓶 (紅色), H 135.610 加熱套內襯，用于 500 ml 圓底燒瓶 (紫色),ETS-D5, ETS-D6, IKAFLON 10 磁力攪拌子, IKAFLON 15 磁力攪拌子, IKAFLON 20 磁力攪拌子, IKAFLON 25 磁力攪拌子, IKAFLON 30 磁力攪拌子, IKAFLON 40 磁力攪拌子,IKAFLON 50 磁力攪拌子, IKAFLON 80 磁力攪拌子, TRIKA 25 三角體磁力攪拌子, TRIKA 42 三角體磁力攪拌子, RS 1 磁力攪拌子套裝, RSE 攪拌子移出棒, H 100 保護罩, PT 1000.60 溫度傳感器, 溫度傳感器，玻璃覆膜, H 38 固定支桿, H 44 夾頭, H 16 V 支桿, H 16.1 延長支桿, H 15 加熱鍋, H 28 加熱鍋, H 29 油浴鍋, H 30 油浴鍋, H11 歐式插頭電源線, H11 中式插頭電源線, H11 英式插頭電源線, H11 美式插頭電源線

Options: H 135.3 heating tray; H 135.313 1/4 heating block, golden, vol 4ml; H 135.314 1/4 heating block, blue, vol 8ml; H 135.315 1/4 heating block, red, 16ml; H 135.310 1/4 heating block, black, 20ml, H 135.311 1/4 green, 30ml, H 135.312 1/4 heating block, orange, 40ml; H 135.4 heating jacket for 100ml round bottom flask; H 135.５ heating jacket for 500ml round bottom flask; H 135.６ heating jacket for 1000ml round bottom flask; H 135.410 heating jacket liner for 10ml round bottom flask (golden); H 135.411 heating jacket liner for 25ml round bottom flask (blue); H 135.412 heating jacket liner for 50ml round bottom flask (red); H 135.510 heating jacket liner for 10ml round flask (golden); H 135.511 heating jacket liner for 25ml round bottom flask (blue); H 135.512 heating jacket liner for 300ml round bottom flask (red); H 135.610 heating jacket liner for 500ml round flask (purple); magnetic stirring bar models ETS-D5, ETS-D6 and IKAFLON 10; magnetic stirring bar model IKAFLON 15; magnetic stirring bar model IKAFLON 20; magnetic stirring bar model IKAFLON 25; magnetic stirring bar model IKAFLON 30; magnetic stirring bar model IKAFLON 40; magnetic stirring bar model IKAFLON 50; magnetic stirring bar model IKAFLON 80; triangular magnetic stirring bar model TRIKA 25; triangular magnetic stirring bar model TRIKA 42; magnetic stirring bar kits model RS1; RSE magnetic stirring bar removing rod; H100 protective cover; PT 1000.60 temperature sensor; temperature sensor; glass film; H38 fixing strut; H44 clamp head; H16V strut; H 16.1 extension strut; H15 heating pan; H28 heating pan; H29 oil bath pot; H30 oil bath pot; H11 power cord for European plug; H11 power cord for Chinese plug; H11 power cord for British plug; H11 power cord for US plug

攪拌點位數目

每個攪拌點位****攪拌量 (H2O) Stir each mixing point maximum amount (H2O)		20
單個攪拌點位的轉速偏差	%	5
****攪拌量 (H2O) Maximum stirring capacity (H2O)		20
電機輸入功率Motor input power	W	16
電機輸出功率Motor output power	W	9
轉速顯示 Speed display		LED
速度范圍 Speed range	1/min	50 - 1500
攪拌子****長度 Maximum length of stirring	mm	80
加熱輸出功率 Heat output power	W	600
加熱速度 1升H2O in H 15)	K/min	6.5
加熱溫度范圍Heating temperature range	°C	50 - 310
加熱溫度控制 Heating temperature control		LED
加熱溫度控制精確度 Heating temperature control accuracy	±K	1
轉速控制 Speed control		無級
可調安全溫度回路最小值 Adjustable safety circuit minimum tempera	°C	50
可調安全溫度回路****值 Adjustable safety circuit max temperature	°C	360
外接溫度傳感器接口 External temperature sensor interface		德國工業標準DIN 12 878
帶傳感器控溫精確度 Control accuracy with sensor	±K	1
工作盤材質 Plate material		鋁合金
工作盤外形尺寸 Working plate dimensions	mm	135
外形尺寸 Dimensions	mm	160 x 85 x 270
重量 Weight	kg	2.5
允許環境溫度 Permissible ambient temperatu	°C	5 - 40
允許相對濕度 Relative humidity allowed	%	80
DIN EN 60529 保護方式 DIN EN 60529 Protection Mode		IP 42
電壓 Voltage	V	220 - 230 / 115 / 100
頻率 Frequency	Hz	50/60
儀器輸入功率 Power input	W	650
